SKI-DOO Grand Touring 670SE Grand Touring 670SE 08- Front Arm 670SE
08- Front Arm 670SE
№ Наименование Примечание Кол-во
2 CUSHION 2
3 HEX. SCREW M10 X 55 (5.000 per pack) 2
4 FLAT WASHER 10 MM (10.000 per pack) 2
5 WASHER-LOCK SPRING DIN.128A-A2 (10.000 per pack) 2
8 ELASTIC LOCKING NUT M10 Formula DLX 500 LC. (10.000 per pack) 2
10 BALL BEARING 4
11 CIRCLIP (10.000 per pack) 4
18 SOCKET HEAD SCREW M8 X 25 (10.000 per pack) 4
19 HEX. FLANGED ELASTIC NUT M8 (10.000 per pack) 4
22 ADJUSTMENT CAM 1
23 SPRING GUIDE 1
25 HEX. SCREW M10 X 45 (10.000 per pack) 2
28 GREASE FITTING (10.000 per pack) 2
32 FLAT WASHER 12 MM (10.000 per pack) 1
33 NUT-STOP ELASTIC DIN.985 (5.000 per pack) 1
35 SOCKET SCREW M10 X 35 (10.000 per pack) 2
39 COTTER PIN (10.000 per pack) 1
41 FLAT WASHER (5.000 per pack) 1
42 ADJUSTER KNOB 1
43 ELASTIC FLANGED NUT M10 (5.000 per pack) 1
45 RONDELLE *WASHER (10.000 per pack) 4
46 LOCTITE 271 10 ML 0
