| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | CLAMP-HOSE13/16"-1 1/2" | 2 | |
| 2 | Hose Engine Outlet Rear | 1 | |
| 3 | CLAMPSPRINGBAND 32/12 (10) (10 per pack) | 9 | |
| 4 | HOSE-90 D LWR RADIATOR | 1 | |
| 5 | CLAMPHOSE(10) (10 per pack) | 2 | |
| 6 | Asm. Tube Coolant | 1 | |
| 7 | Hose Radiator Lower | 1 | |
| 8 | Hose Engine Inlet Rear | 1 | |
| 9 | Bracket Radiator Mount Lower | 1 | |
| 10 | Hose Radiator | 1 | |
| 11 | CONNECTOR-TEE1"1"1" BARBED | 1 | |
| 12 | SCREW | 8 | |
| 14 | SHROUD-FAN | 1 | |
| 15 | SCREW(10) (10 per pack) | 10 | |
| 16 | GROMMET/INSERT-ASM | 2 | |
| 17 | FILLER-REMOTECOOLANT2FITTING | 1 | |
| 18 | CAP-PRESSURE13 PSI | 1 | |
| 19 | ASM-RADIATORCORE | 1 | |
| 20 | BUSHING-MOUNTLOWER RADIATOR | 2 | |
| 21 | CLAMPSPRINGBAND 35/12BLK | 2 | |
| 22 | CLIP-"U"M6.0X1.0 | 4 | |
| 23 | SCREW | 2 | |
| 24 | Hose Radiator Upper | 1 | |
| 25 | CABLE TIE14" | 1 | |
| 26 | LINEFUEL1/4 ID(1525 CM.) [BULK SVC] | 0 | |
| 27 | FITTING90 DEGREE (10) (10 per pack) | 1 | |
| 28 | SCREW(10) (10 per pack) | 4 | |
| 29 | BRACKET FILLER NECK | 1 | |
| 30 | TANK-SURGE | 1 | |
| 31 | CAPPLUG9X(GRN)FLEX TEMP(10) | 1 | |
| 32 | GASKET (10) (10 per pack) | 1 | |
| 33 | CAP OVERFLOW | 1 | |
| 34 | Bracket Mount Radiator Upper Black | 1 |
